Description:

HVAC Motor, Motor Application: HVAC/R, Motor Sub Application: Direct Dr Fan/Blower, Motor Design: Shaded Pole, Motor Enclosure Design: Totally Enclosed Nonventilated, Duty: Continuous, HP: 1/60, Nameplate RPM: 3000, Voltage: 115, Frame: 3. 3, Service Factor: 1. 0, Full Load Amps: 0. 75, Hz: 60, Motor Shaft Rotation: CWSE, Insulation Class: A, Max. Ambient Temp. : 40 Degrees C, Number of Speeds: 1, Motor Mounting Type: Stud, Bearings: Sleeve, Motor Thermal Protection: Auto, Body Dia. : 3. 3", Shaft Dia. : 1/4", Shaft Length: 1-3/4", Length Less Shaft: 2-3/8", Stud Location: 4/BE, Stud/Base Mtg. Pattern: 2-7/8 x 2-7/8", Phase: 1, Motor Shaft Design: Flat, Application: HVAC/R, RPM Range: 1801-3000, Mounting Pattern: 2-7/8 x 2-7/8 Model # D402 Features: 1/60 HP 115 Volts 3000 RPM.
