Description:

Parameters: Working Voltage: 80 260VAC Measuring Range: 80 260VAC Rated Power: 100A/22000W Operating Frequency: 45-65Hz Measuring Accuracy: 1. 0 grade Test range and display format: Power Range: 022kW within 1kW, display 0. 0999. 9W; within 1kW10kW, display 10009999W; 10kW and above, display 10. 022. 0kW. Energy Range: 09999kWh within 10KWh, display 09999Wh; 10kWh and above, display 109999kWh. Voltage Range: 80260V(display 80260V) Current Range: 0100A(display 0. 0099. Applied load should not exceed the rated power. Wiring order can't be wrong. Packing Includes: 1x AC Power Multimeter Perfect to work with a generator or solar panel setup, also great to monitor accumulated energy usage on devices that cycle on and refrigerator, dehumidifier, washing machine, wall a/C unit) and the phantom load(cable Modem, router, dvr)Multifunctional: the accumulated energy can be reset by button; store data when power off; power alarm threshold preset function; overload alarm function (over power alarm threshold, backlight and power will Flash to alarm)Display has great visibility, very bright and Clear; the Blue backlight can be turned on/off by the front accessible recessed switch located on the Right side bezelVoltage test range: AC 80260v; current test range: 0100a; power test range: 022kw; energy test range: 09999kwhIt is a compact, lightweight and functional multi-meter, with large-screen LCD display, can display Voltage, current, active power and energy at the same time it does NOT control or effect the load in any wayModel # 200123.
