Description:

Features: Sub-drain valve to simulate circuits and solid state electronic timer solenoid valve to match the compressed air system to achieve automatic timed condensate discharge Widely used in filters, separators, dryers, gas tank, drip legs and other compressed air system components There are test button and the intervals, emission time adjustment knob Easy to install, fully automatic operation Specifications: Time interval (OFF): 0. 5--45 minutes Discharge time (ON): 0. 5--10 seconds Manual test button ( micro switch ) Power supply voltage: 220V AC/24V DC 50/60Hz The current consumption of the largest 4mA Ambient temperature: -40C to 60C Shell material: Flame retardant ABS plastic Electrical connection: DIN43650A Indicator lamp: LED indicating power on / off Type: two two direct-acting valve In / out port size: 1/2" Maximum working pressure: 1. 6Mpa Maximum temperature: 90C Forging brass valve, flow aperture of 5 mm Insulation: class H Protection grade: IP65 Package Includes: 1 x Air Compressor Tank Drain Valve Features: Power Supply Voltage: 220V AC/24V DC 50/60Hz In / Out Port Size: 1/2" Maximum Working Pressure: 1. 6Mpa Maximum Temperature: 90C.
