Description:

The load ratings fit a wide variety of manufacturing and warehousing uses. The rivet hydraulically compressed kingpin to increase strength of swivel section as compared to staking. Cold formed top plate, yoke and button are all heat treated to prevent brinelling, improve swivel and increase service life. Load and thrust bearings are hardened and ground and rotate on hardened raceways. Top plate and legs are 1/4" steel. Legs are formed for increased strength and continuously welded to yoke. All swivel sections are equipped with a lubrication fitting for field maintenance. RWM lubricates all swivel sections prior to shipment. Notched yokes are standard. 1-1/2" tread wheel. This medium duty caster series is designed for use on scrbins, parts boxes, dollies and racks. Mounting plate size is 4" x 4-1/2" x 1/4". Model # 40-DUR-0515-R-TG Features: 6-1/8" Overall height, 1-3/8" swivel lead and 650lbs capacity Durastan wheel with roller bearing 2-5/8" x 3-5/8" slotted to 3" x 3" bolt hole spacing for 3/8" diameter bolt Cold formed top plate, yoke and button are all heat treated to prevent brinelling, improve swivel and increase service life with a 5/8" diameter kingpin Zinc plated to protect against corrosion.
